The Accuenergy Acuvim IIBN has a built-in BACnet communication module specifically designed to monitor and collect real-time revenue-grade electrical data for building control and automation applications. This model includes the Acuvim IIBN basic unit with 333mV current transformer input, a 20 to 60V DC power supply, and an integrated mounting option with LCD display.
Features
Applications
The Acuvim IIBN is specially designed for these applications.
| Current Inputs | |
| Nominal Current | Channel 1 (5A), Channel 2 (1A), Channel 3 1A(333mV), Channel 4 1A(100mV Rope-CT), Channel 5 1A(80mA/100mA/200mA) |
| Metering Range | Channel 1 (0~10A), Channel 2 (0~2A), Channel 3 (0~1.2A), Channel 4 (0~1.2A), Channel 5 (0~1.2A) |
| Pickup Current | Channel 1 (5mA), Channel 2 (1mA), Channel 3 (5mA), Channel 4 (5mA), Channel 5 (5mA) |
| Withstand | 20Arms Continuous, 0.1% of Nominal, 100Arms for 1 second, Non-Recurring |
| Burden | 0.05VA (Typical) @ 5Arms |
| Accuracy | 0.2% Full Scale |
| Voltage Inputs | |
| Nominal Full Scale | 400Vac L-N, 690Vac L-L (+20%) |
| Withstand | 1500Vac Continuous, 2500Vac, 50/60Hz for 1 Minute |
| Input Impedance | 2Mohm per Phase |
| Metering Frequency | 45Hz~65Hz, 300Hz ~ 500Hz |
| Pickup Voltage | 10Vac |
| Accuracy | 0.2% Full Scale |
| AC/DC Control Power | |
| Operating Range | 100~415Vac, 50/60Hz; 100~300Vdc |
| Burden | 5W |
| Frequency | 50/60Hz |
| Withstand | 3250Vac, 50/60Hz for 1 minute |
| AC/DC Control Power | |
| Operating Range | 100~415Vac, 50/60Hz; 100~300Vdc |
| Burden | 5W |
| Frequency | 50/60Hz |
| Withstand | 3250Vac, 50/60Hz for 1 minute |
| Operating Environment | |
| Operation Temperature | - 40 to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
