The CA7027 Fault Mapper Pro® is a hand-held graphical TDR (Time Domain Reflectometer) designed for identifying and locating faults on power and communication cables, given access to one end only.
The Fault Mapper Pro® measures cable length and indicates the length and distance to cable faults to a range of 9 ft (3 m) to 19,000 ft (6000m) on virtually any type of cable. It injects a series of pulses into the cable under test. The velocity at which the pulses travel is determined by the type of cable, which is known as the velocity of propagation (Vp) of the cable. The Velocity of Propagation (Vp) is adjustable between 1% and 99% enabling accurate calibration to the cable under test.
The Vp value is expressed as a percentage of the speed of light (e.g. 67% or ft/mtrs/micro-second), this value will vary according to the type of cable under test. The Fault Mapper Pro® can accept user selectable values between 1 and 99% (or the equivalent value in feet or meters per micro-second).
Based on the selected Vp and the time taken for the pulses to travel through the cable, a reflection profile of the cable under test is displayed. An adjustable cursor assists in locating faults and termination.
The Fault Mapper Pro® incorporates an oscillating tone tracer, which is detectable with a standard tone tracer, for use in the tracing and identification of cable pairs.
Features
Applications
| Ranges @ Vp=70% | 23, 49, 98, 197, 394, 820, 1640, 3280, 6560, 9850, 19000ft |
| Range Selection | Manual range control |
| Accuracy | ±1% of range |
| Resolution | Approximately 1% of selected range |
| Minimum Cable Length | 1.5 ft (0.5m) |
| Sensitivity | Minimum 3 pixel return on a fault at 4km on 0.6mm 0, PE, TP |
| Vp (Velocity of Propagation) | Adjustable from 1% to 99% |
| Output Pulse | +5V peak to peak into an open circuit |
| Output Impedance | Selectable between 25, 50, 75 & 100Ω |
| Output Pulse Width | 3 ns to 3 ms, Automatic with range |
| Scan Rate | 2 scans / second or scan held |
| Tone Generator | Oscillating tone 810Hz - 1110Hz |
| Voltage Protection | 250V AC |
| Power Supply | 4 x 1.5V AA Alkaline batteries |
| Battery Life | 60 hours continuous scanning |
| Auto-off | Selectable 1, 2, 3, 5 minutes or disabled |
