Each probe retains its own unique calibration information, allowing for full probe interchangeability. PosiTector Smartlink compatible, connect your probe to your smartphone or tablet wirelessly and effortlessly.
Simple
Accurate
Powerful
Durable
Versatile
Includes all of these, PLUS:
USB Keyboard mode enables PosiTector Advanced instruments to emulate a USB keyboard when connected to a computer.
USB Keyboard mode communicates with your computer by emulating keyboard keystrokes. When connected in this mode, PosiTector Advanced instruments will be recognized as a simple USB keyboard. Each reading is typed, followed by a carriage return (enter). This provides a simple way to capture readings as they are taken without any special software, drivers or complex setup.
Built into the PosiTector Advanced gauge is the ability to stream readings over WiFi. If WiFi Streaming is enabled in the WiFi menu, the gauge will send a GET request to specified URL for each reading. The URL can contain tags which are replaced by the PosiTector with values corresponding to the reading. This solution turns the PosiTector gauge body into an Internet of Things device and is ideal for users with an existing WiFi network and a desire to stream live readings to a central application or database.
How to use WiFi Streaming
PosiTector Advanced allows live streaming of measurement values to a USB connected computer.
Any software that accepts data via a serial interface can be configured to accept the PosiTector data stream.
The PosiTector creates a virtual serial port, a protocol commonly used by applications to communicate with external tools and devices. PosiTector measurements can be captured as they are taken in real-time, including metadata such as the units and measurement type.
Any serial-compatible software can be configured to accept the PosiTector data stream. Proficient (by InfinityQS) and WinSPC (by DataNet systems) are two popular statistical process control (SPC) software options.
This solution is ideal for users who want the reliability and simplicity of a wired connection.
Proficient
WinSPC
WiFi wireless technology is included with all PosiTector Advanced models Automatic Adhesion Testers with touchscreen display.
Any device connected on the same WiFi network can wirelessly access the gauge's stored measurement data to:
This solution is ideal for users who want to store readings in the PosiTector gauge body to be transferred to another device at a later date.
Range | 0 to 250 mils 0 to 6 mm (0 to 6000 ?m) |
Accuracy | ±(0.5 mil + 1%) 0 to 100 mils ±(0.5 mil + 3%) >100 mils ±(0.01 mm + 1%) 0 to 2.5 mm ±(0.01 mm + 3%) >2.5 mm |
Dimensions | 5 x 2.6 x 1" (127 x 66 x 25.4 mm) |
Weight | 0.3 lbs (137 g) |
