Features
Control methods
Control methods include ON/OFF, PID, self-tune and manual tune. PID control is supported with 64 ramp/soak control actions. Two additional alarm outputs are standard. The alarm outputs can be quickly configured by using the thirteen built-in alarm functions.
Communication
This controller easily communicates with other external devices such as PC's and PLC's for data search and system integration using the built-in RS-485 interface. Up to 247 communication addresses are available with transmission speeds of 2400 to 38,400 bps. Also features universal input, selectable °F/°C, selectable resolution and security functions.
Applications
| Inputs | Thermocouple, RTD, DC voltages or DC current |
| Display | Two 4-digit, 7 segment 0.25" (6.35 mm) LEDs PV: Red SV: Green |
| Accuracy | ±0.25% span, ±1 least significant digit |
| Memory Backup | Nonvolatile memory |
| Output | 1: Current 2: Relay |
| Control Output Ratings | Relay: SPST, 5 A at 250 V AC resistive Current: 4 to 20 mA |
| Communication | RS-485 Modbus® ASCII/RTU communication protocol |
| Operating Temperature | 32 to 122°F (0 to 50°C) |
| Supply Voltage | 24 V DC |
| Power | Requirements: 24 V DC Consumption: 5 V A maximum |
| Front Panel Rating | IP56 |
| Agency Approvals | CE, cULus |
| Dimensions | 1.89 x 1.89 x 3.54" (48 x 48 x 89.5 mm) |
| Weight | 4 oz (114 g) |
