NOTE: May be used with Hydrogen where pressures are less than 35 psi.
Specifications: Service: Aluminum Case: Air and compatible gases and oil based liquids.
Brass Case: Air and compatible gases and water based liquids.
Wetted Materials: Consult factory.
Housing: Die cast aluminum with impregnated hard coating, standard.
Optional forged brass housing is required for water or water based fluids.Special material diaphragms available, contact factory.
Accuracy: ±3% of full scale at 70°F (21.1°C).
(±2% on 4000S models, ±4% on 4200, 4210, 4215, 4220, 4300, 4400, and 4500).
Pressure Limits: -20" Hg to 500 psig.
(-0.677 bar to 34.4 bar).
Temperature Limits: 20 to 200°F (-6.67 to 93.3°C).
Size: 4" (101.6 mm) diameter dial face.
Mounting Orientation: Diaphragm in vertical position.
Consult factory for other position orientations.
Process Connections: 1/4" female NPT high and low pressure taps, duplicated - one pair top for air and gas, and one pair bottom for liquids.
Weight: 3 lb, 3 oz (1.45 kg) aluminum case; 7 lb, 13 oz (3.54 kg) brass case.
Standard Accessories: Two 1/4" NPT plugs for duplicate pressure taps, four flush mounting adapters with screws and four surface mounting screws.
| Service | Aluminum Case: Air and compatible gases and oil based liquids Brass Case: Air and compatible gases and water based liquids |
| Housing | Die cast aluminum with impregnated hard coating, standard. Optional forged brass housing is required for water or water based fluids.Special material diaphragms available, contact factory. |
| Accuracy | ±3% of FS at 70°F (21.1°C) (±4% on 4200, 4210, 4215, 4220, 4300, 4400, and 4500) |
| Pressure Limits | -20" Hg to 500 psig (-0.677 bar to 34.4 bar) |
| Temperature Limits | 20 to 200°F (-6.67 to 93.3°C) |
| Mounting Orientation | Diaphragm in vertical position |
| Process Connections | ¼" female NPT high and low pressure taps, duplicated - one pair top for air and gas, and one pair bottom for liquids |
| Dimensions | 4" (101.6 mm) diameter dial face |
| Weight | Aluminum case: 3 lb, 3 oz (1.45 kg) Brass case: 7 lb, 13 oz (3.54 kg) |
