Dwyer 4320 Capsuhelic Differential Pressure Gauge (10-0-10"w.c.)

No reviews yet Write a Review
$825.63
SKU:
4320
Condition:
New
Availability:
In Stock
5 customers are viewing this product

Dwyer 4320 Capsuhelic Differential Pressure Gauge (10-0-10"w.c.)

$825.63

Dwyer 4320 CAPSUHELIC, DIFFERENTIAL PRESSURE GAUGE, 10/0/10

  • Using the basic design of Dwyer's time-proven Magnehelic® gauge, the Capsuhelic® gauge contains a simple, frictionless movement that permits full scale readings as low as 0.5 inch water column.
  • The pressure being measured is held within a capsule which is an integral part of the gauge.
  • This containment of the pressure permits the use of the gauge on system pressures of up to 500 psig, even when differentials to be read are less than 0.1 inch w.c.
  • The diaphragm-actuated Capsuhelic® gauge requires no filling liquid which might limit its outdoor applications.
  • Zero and range adjustments are made from outside the gauge, and there is no need to disassemble the gauge in normal service.

NOTE: May be used with Hydrogen where pressures are less than 35 psi.
Specifications: Service: Aluminum Case: Air and compatible gases and oil based liquids.
Brass Case: Air and compatible gases and water based liquids.
Wetted Materials: Consult factory.
Housing: Die cast aluminum with impregnated hard coating, standard.
Optional forged brass housing is required for water or water based fluids.Special material diaphragms available, contact factory.
Accuracy: ±3% of full scale at 70°F (21.1°C).
(±2% on 4000S models, ±4% on 4200, 4210, 4215, 4220, 4300, 4400, and 4500).
Pressure Limits: -20" Hg to 500 psig.
(-0.677 bar to 34.4 bar).
Temperature Limits: 20 to 200°F (-6.67 to 93.3°C).
Size: 4" (101.6 mm) diameter dial face.
Mounting Orientation: Diaphragm in vertical position.
Consult factory for other position orientations.
Process Connections: 1/4" female NPT high and low pressure taps, duplicated - one pair top for air and gas, and one pair bottom for liquids.
Weight: 3 lb, 3 oz (1.45 kg) aluminum case; 7 lb, 13 oz (3.54 kg) brass case.
Standard Accessories: Two 1/4" NPT plugs for duplicate pressure taps, four flush mounting adapters with screws and four surface mounting screws.

Dwyer 4320 Specifications

Service Aluminum Case: Air and compatible gases and oil based liquids
Brass Case: Air and compatible gases and water based liquids
Housing Die cast aluminum with impregnated hard coating, standard. Optional forged brass housing is required for water or water based fluids.Special material diaphragms available, contact factory.
Accuracy ±3% of FS at 70°F (21.1°C)
(±4% on 4200, 4210, 4215, 4220, 4300, 4400, and 4500)
Pressure Limits -20" Hg to 500 psig (-0.677 bar to 34.4 bar)
Temperature Limits 20 to 200°F (-6.67 to 93.3°C)
Mounting Orientation Diaphragm in vertical position
Process Connections ¼" female NPT high and low pressure taps, duplicated - one pair top for air and gas, and one pair bottom for liquids
Dimensions 4" (101.6 mm) diameter dial face
Weight Aluminum case: 3 lb, 3 oz (1.45 kg)
Brass case: 7 lb, 13 oz (3.54 kg)
