Specifications
Service: Air and non-corrosive gases.
Wetted Materials: Ranges 5" and Greater: glass, PVC, silicon, alumina ceramic, epoxy, RTV, gold, aluminum, stainless steel and nickel; Ranges 1" and Lower: stainless steel, silicone, gold, ceramic.
Housing Materials: Aluminum, glass.
Accuracy: ±0.5% at 77°F (25°C) including hysteresis and repeatability (after 1 hour warm-up).
Stability: < ±1% per year.
Pressure Limits: Ranges ? 2.5" w.c.: 2 psi; 5" w.c.: 5 psi; 10" w.c.: 5 psi; 25" w.c.: 5 psi; 50" w.c.: 5 psi; 100" w.c.: 9 psi.
Temperature Limits: -40 to 160°F (-40 to 71.1°C).
Compensated Temperature Limits: 32 to 140°F (0 to 60°C).
Thermal Effects: 0.020%/°F (0.036/°C) from 77°F (25°C).
Power Requirements: 10-35 VDC.
Output Signal: 4-20 mA DC.
Zero & Span Adjustments: Accessible via menus.
Response Time: 250 ms (damping set to 1).
Display: 4 digit LCD 0.6" height.
Electrical Connections: M-12 4 PIN Connector.
Process Connections: 1/8" female NPT.
Enclosure Rating: Designed to meet NEMA 4X (IP66).
Mounting Orientation: Mount unit in horizontal plane.
Weight: 2 lb 10 oz (1.19 kg).
Agency Approvals: FM Intrinsically Safe CLI Div I GR: A, B, C, D; CLII Div I GR: E, F, G; CLIII Div I. CE: CENELEC EN 61326/55024: 2003; IEC 61000-4-2/3/4/6: 2001/2006/2004/2005; CENELEC EN 55011: 2006; 2004/108/EC EMC Directive.
| Service | Air and non-combustible gases |
| Wetted Materials | Ranges 5 "w.c. and Greater: glass, PVC, silicon, alumina ceramic, epoxy, RTV, gold, aluminum, stainless steel and nickel Ranges 1 "w.c. and Lower: stainless steel, silicone, gold, ceramic |
| Housing Materials | Aluminum, glass |
| Accuracy | ±0.5% at 77°F (25°C) including hysteresis and repeatability (after 1 hour warm-up) |
| Stability | <±1% per year |
| Pressure Limits | Ranges ?2.5 "w.c.: 2 psi 5 "w.c.: 5 psi 10 "w.c.: 5 psi 25 "w.c.: 5 psi 50 "w.c.: 5 psi 100 "w.c.: 9 psi |
| Temperature Limits | 32 to 140°F (0 to 60°C) |
| Compensated Temperature Limits | 32 to 140°F (0 to 60°C) |
| Thermal Effects | 0.020%/°F (0.036/°C) from 77°F (25°C) |
| Power Requirements | 10 to 35 VDC |
| Output Signal | 4 to 20 mA DC |
| Zero and Span Adjustments | Accessible via menus |
| Response Time | 250 ms (damping set to 1) |
| Display | 4 digit LCD 0.6" height |
| Electrical Connections | M-12 4 PIN Connector |
| Process Connections | ?" female NPT |
| Enclosure Rating | Designed to meet NEMA 4X (IP66) |
| Mounting Orientation | Mount unit in vertical plane |
| Weight | 2 lb 10 oz (1.19 kg) |
| Agency Approvals | CE: CENELEC EN 61326/55024: 2003; IEC 61000-4-2/3/4/6: 2001/2006/2004/2005; CENELEC EN 55011: 2006; 2004/108/EC EMC Directive; FM Intrinsically Safe CLI Div I GR: A, B, C, D; CLII Div I GR: E, F, G; CLIII Div I |
