Kyoritsu 1051 Digital Multimeter, RMS, 6000

No reviews yet Write a Review
$609.89
SKU:
1051
Availability:
2 to 3 Weeks
5 customers are viewing this product

Kyoritsu 1051 Digital Multimeter, RMS, 6000

$609.89

Availability: 2 to 3 Weeks

Kyoritsu 1051 Offers

Features

  • High accuracy, high performance and reliable measurements
  • Top accuracy: 0.09% basic DC accuracy
  • Dual display: Large display with 6000 counts, bar graph with 31 segments, and white back light display
  • True-RMS measurements: Ensures accurate readings, avoids errors (of up to 50%) which can occur when non-sinusoidal wave-forms, created by common non linear loads such PCs, inverters, switch mode power supplies, etc, are measured
  • Low-pass filter for motor drive measurements: AC measurement can be limited to low frequency, helping for instance voltage measurements in the presence of variable speed motor drivers or inverters
  • The low-pass filter can be switched ON/OFF
  • User calibration function: Calibration and adjustment are possible by simple operation of DMM keys
  • The DMM measures the output voltage of an external sensor (e.g. clamp sensor, light sensor, temperature sensor, etc.) in the secondary display, while the primary display can be set to show the unit of the measured parameter (e.g. A, mA, Lux, °C) according to the conversion ratio chosen
  • Safety design for industrial use
  • Relative and percentage calculation: Can calculate and display relative values or percentage (%) against the reference measurement values
  • Complies with IEC 61010-1 CAT IV 600 V, CAT III 1000 V
  • Terminal shutter to prevent incorrect test leads' insertion in current terminals
  • Very wide operating temperature range from 14 to 131°F (-10 to 55°C)

Auto Hold Function

The measured value is held on the display just by removing the test leads from the circuit under test. Users can remain safely concentrated on the measuring point without the need to press the "Hold" key.

Applications

  • Electrical and electronic troubleshooting


Kyoritsu 1051 Specifications

Specifications

DC V
Range600.0mV/6.000V/60.00V/600.0V/1000V
Accuracy600.0mV/6.000V/60.00V/600.0V: 0.09+2 1000V: 0.15+2
Input Impedance600.0mV/60.00V/600.0V/1000V: 10MΩ 6.000V: 11MΩ
Overload Protection1000V DC 1000V rms AC
AC V
Range600.0mV/6.000V/60.00V/600.0V/1000V
Accuracy50/60Hz: 0.5+5 40 to 500Hz: 1+5 500Hz to 1kHz: 1.5+5 (except for 1000V)
Input Impedance600.0mV: 10MΩ<200pF 6.000V: 11MΩ<50pF 60.00V/600.0V/1000V: 10MΩ<50pF
Overload Protection1000V rms AC 1000V DC
DC A
Range600.0µA/6000µA/60.00mA/440.0mA/6.000A/10.00A
Accuracy600.0µA/6000µA/60.00mA: 0.2+2 440.0mA/6.000A/10.00A: 0.5+5
Voltage Drop600.0µA/6000µA: <0.12mV/µA 60.00mA/440.0mA: <3.3mV/mA 6.000A/10.00A: <0.1V/A
Overload Protection600.0µA/6000µA/60.00mA/440.0mA: 440mA Protected by a 40mA/1000V fuse 6.000A/10.00A: 10A Protected by A 10.00A 10A/1000V fuse
AC A
Range600.0µA/6000µA/60.00mA/440.0mA/6.000A/10.00A
Accuracy50/60Hz: 0.75+5 40Hz to 1kHz: 1.5+5
Voltage Drop600.0µA/6000µA: <0.12mV/µA 60.00mA/440.0mA: <3.3mV/mA 6.000A/10.00A: <0.1V/A
Overload Protection600.0µA/6000µA/60.00mA/440.0mA: 440mA Protected by a 40mA/1000V fuse 6.000A/10.00A: 10A Protected by A 10.00A 10A/1000V fuse


What's included with the Kyoritsu 1051
  • RMS Multimeter
  • Test Leads
  • 2 x Fuses
  • Instruction Manual
