Megger DET3TD 3-Terminal Digital Ground Tester, 0.01 to 2000 ?

No reviews yet Write a Review
$1,470.28
15 sold in last 9 hour
SKU:
DET3TD
Condition:
New
Availability:
In Stock
5 customers are viewing this product

Megger DET3TD 3-Terminal Digital Ground Tester, 0.01 to 2000 ?

$1,470.28

Megger DET3TD

Highly reliable, this ground tester automatically checks the connection and conditions of the P spike, C spike, and the level of ground noise, indicating the status on the display. The tester also a voltmeter to enable the measurement of ground voltage.

Features

  • 2 and 3 point testing
  • Microprocessor control for improved error detection
  • User selectable test voltage (25/50 V)
  • Choice of digital or analog display
  • Warning indicators prevent test failure
  • Simple one button operation
  • Clear, unambiguous warnings and error indications ensure the reliability of the reading and reduce test time
  • Large, clear LCD that can be read in ambient lighting
  • Noise rejection to 40 V peak to peak allows accurate testing in noisy environments
  • Accuracy of 2% of reading enhances reliability of measurement

Applications

  • Primary and secondary electrical grounding systems
  • Utility pole grounds
  • Lightning protection systems
  • Residential grounds
  • Machinery safety grounds
  • Computer and communication system grounds
  • EMI/RFI system grounds
  • Antenna and pedestal grounds
  • CATV system grounds

Megger DET3TD Specifications

Resistance Range 0.01 to 2000 ? autoranging
Resistance Accuracy 2P measurements: 2% ±3 digits
3P measurements: 2% ±3 digits
Maximum Probe Resistance Rp limit: 100 k? (50 V output voltage)
Rc limit: 100k? (50 V output voltage)
Limits reduced to 50 k? for 25 V output voltage
Limits reduced to 5 k? for 0.01 ? resolution on 18 ? range
Earth Voltage Range: 0 to 100 V
Accuracy: 2% ±2 V
2- and 3-Wire Test Yes
Ground Current Range (with Current Measuring Clamp) 0.5 mA to 19.9 A
Ground Current Accuracy 5% ±3 digits
Test Frequency: 128 Hz
Voltage: 25 V or 50 V, user selectable (factory setting 50 V
Current: 450 mA or 4.5 mA
Noise Rejection: 40 V peak to peak
Check: Automatic
C Spike Check Automatic
P Spike Check Automatic
General Specifications
Temperature Operating: -5 to 131°F (-15 to 55°C)
Storage: 40 to 158°F (-40 to 70°C)
Humidity: 95% RH non-condensing at 104°F (40°C)
Display LCD
Terminals 4 mm plug type (test leads)
Battery 8 x 1.5 V AA cell
Battery Life 3 hours, 700 consecutive tests
Safety EN61010-1 CAT IV 100 V
Ingress Protection IP54
EMC Meets the requirements of EN61326-1:1998 for use in heavy industrial areas
Dimensions 8 x 5.7 x 3.2" (203 x 148 x 78 mm)
Weight 2.2 lbs (1 kg)
