The Megger MJ15 5 kV Analog Insulation Tester Features: the dual power supply option.
The MJ15 is a compact 5kV insulation tester. It is very simple to use and provides a quick and accurate reading of insulation resistance. The instruments use an analog display with a maximum reading of 20 GO.
Features:
| Insulation Range | 100 k? to 20 G? (also 0 ? and ?) |
| Test Voltages (dc) | 500 V, 1000 V, 2500 V & 5000 V |
| Test Voltage Accuracy | ±5% of nominal test voltages on 20 M? load |
| Test Voltage Stability | &±1% (180 r.p.m. to 240 r.p.m. MJ15) |
| Insulation Accuracy | (at 0 - 30° C) ±2.5% of full scale deflection |
| Short Circuit Current | 1.5 mA ± 0.5 mA |
| Maximum Capacitance of Load | 5 µF |
| Interference Rejection | 1 mA rms at 50 to 60 Hz |
| Discharge Resistor | <500 k? |
| VOLTAGE RANGE | |
| Range | 0 to 600 V ac Indication of dc |
| Accuracy | ± 2.5% f.s.d. ac (with rotary switch in the V position) |
| General | |
| Overload Rating | 720 V ac or dc |
| Scale Length | 2.8 in. (72 mm) (96°) |
| Power Supply | |
| BM15 | 8 x AA cells (LR6 or rechargeable) |
| MJ15 | Low voltage brushless Generator and 8 x AA cells (LR6 or rechargeable) |
| Battery Life | Typically 2000 five second tests at 5 kV on 100 M? load |
| Battery Indicator | Loaded battery test |
| Safety | Meets the safety requirements for double insulation to IEC 1010-1 (1995) EN61010 (1995) to installation Category III***, 300 V phase to earth (ground) or 600 V Category I* ***Relates to transient overvoltage likely to be found in fixed installation wiring. *Relates to transient overvoltage likely to be found in special equipment or parts of equipment, telecommunication, electronic etc. |
| Non Replaceable Fuse | 1 Amp, 250 V, HBC type (F) (20 mm x 5 mm) to IEC 127/1 This fuse protects the instrument against any faults occurring when using rechargable batteries. |
| E.M.C | Meets EN 50081-1 and EN 50082-1 (1992) with a maximum error of ±5% f.s.d. in areas of high R.F. |
| Temperature Range | |
| Operating | 32° F to 86° F (0° C to 30° C) at full specification -4° F to 122° F (-20° Co 50° C) with temperature coefficient ±0.1%/°C |
| Storage | -13° F to 149° F (-25° C to 65° C) |
| Humidity Range | 90% RH at 104° F (40° C) |
| Dimensions | 8.9 in. x 6.3 in. x 4.5 in. (220 mm x 160 mm x 115 mm) |
| Weight | |
| BM15 | Approx 2.6 lbs (1.2 kg) |
| MJ15 | Approx 3.5 lbs (1.6 kg), or 4 lbs (1.8 kg) with battery holder and cells. |
| Insulation Range | 100 k? to 20 G? (also 0 ? and ?) |
| Test Voltages (dc) | 500 V, 1000 V, 2500 V & 5000 V |
| Test Voltage Accuracy | ±5% of nominal test voltages on 20 M? load |
| Test Voltage Stability | &±1% (180 r.p.m. to 240 r.p.m. MJ15) |
| Insulation Accuracy | (at 0 - 30° C) ±2.5% of full scale deflection |
| Short Circuit Current | 1.5 mA ± 0.5 mA |
| Maximum Capacitance of Load | 5 µF |
| Interference Rejection | 1 mA rms at 50 to 60 Hz |
| Discharge Resistor | <500 k? |
| VOLTAGE RANGE | |
| Range | 0 to 600 V ac Indication of dc |
| Accuracy | ± 2.5% f.s.d. ac (with rotary switch in the V position) |
| General | |
| Overload Rating | 720 V ac or dc |
| Scale Length | 2.8 in. (72 mm) (96°) |
| Power Supply | |
| BM15 | 8 x AA cells (LR6 or rechargeable) |
| MJ15 | Low voltage brushless Generator and 8 x AA cells (LR6 or rechargeable) |
| Battery Life | Typically 2000 five second tests at 5 kV on 100 M? load |
| Battery Indicator | Loaded battery test |
| Safety | Meets the safety requirements for double insulation to IEC 1010-1 (1995) EN61010 (1995) to installation Category III***, 300 V phase to earth (ground) or 600 V Category I* ***Relates to transient overvoltage likely to be found in fixed installation wiring. *Relates to transient overvoltage likely to be found in special equipment or parts of equipment, telecommunication, electronic etc. |
| Non Replaceable Fuse | 1 Amp, 250 V, HBC type (F) (20 mm x 5 mm) to IEC 127/1 This fuse protects the instrument against any faults occurring when using rechargable batteries. |
| E.M.C | Meets EN 50081-1 and EN 50082-1 (1992) with a maximum error of ±5% f.s.d. in areas of high R.F. |
| Temperature Range | |
| Operating | 32° F to 86° F (0° C to 30° C) at full specification -4° F to 122° F (-20° Co 50° C) with temperature coefficient ±0.1%/°C |
| Storage | -13° F to 149° F (-25° C to 65° C) |
| Humidity Range | 90% RH at 104° F (40° C) |
| Dimensions | 8.9 in. x 6.3 in. x 4.5 in. (220 mm x 160 mm x 115 mm) |
| Weight | |
| BM15 | Approx 2.6 lbs (1.2 kg) |
| MJ15 | Approx 3.5 lbs (1.6 kg), or 4 lbs (1.8 kg) with battery holder and cells. |
| Insulation Range | 100 k? to 20 G? (also 0 ? and ?) |
| Test Voltages (dc) | 500 V, 1000 V, 2500 V & 5000 V |
| Test Voltage Accuracy | ±5% of nominal test voltages on 20 M? load |
| Test Voltage Stability | &±1% (180 r.p.m. to 240 r.p.m. MJ15) |
| Insulation Accuracy | (at 0 - 30° C) ±2.5% of full scale deflection |
| Short Circuit Current | 1.5 mA ± 0.5 mA |
| Maximum Capacitance of Load | 5 µF |
| Interference Rejection | 1 mA rms at 50 to 60 Hz |
| Discharge Resistor | <500 k? |
| VOLTAGE RANGE | |
| Range | 0 to 600 V ac Indication of dc |
| Accuracy | ± 2.5% f.s.d. ac (with rotary switch in the V position) |
| General | |
| Overload Rating | 720 V ac or dc |
| Scale Length | 2.8 in. (72 mm) (96°) |
| Power Supply | |
| BM15 | 8 x AA cells (LR6 or rechargeable) |
| MJ15 | Low voltage brushless Generator and 8 x AA cells (LR6 or rechargeable) |
| Battery Life | Typically 2000 five second tests at 5 kV on 100 M? load |
| Battery Indicator | Loaded battery test |
| Safety | Meets the safety requirements for double insulation to IEC 1010-1 (1995) EN61010 (1995) to installation Category III***, 300 V phase to earth (ground) or 600 V Category I* ***Relates to transient overvoltage likely to be found in fixed installation wiring. *Relates to transient overvoltage likely to be found in special equipment or parts of equipment, telecommunication, electronic etc. |
| Non Replaceable Fuse | 1 Amp, 250 V, HBC type (F) (20 mm x 5 mm) to IEC 127/1 This fuse protects the instrument against any faults occurring when using rechargable batteries. |
| E.M.C | Meets EN 50081-1 and EN 50082-1 (1992) with a maximum error of ±5% f.s.d. in areas of high R.F. |
| Temperature Range | |
| Operating | 32° F to 86° F (0° C to 30° C) at full specification -4° F to 122° F (-20° Co 50° C) with temperature coefficient ±0.1%/°C |
| Storage | -13° F to 149° F (-25° C to 65° C) |
| Humidity Range | 90% RH at 104° F (40° C) |
| Dimensions | 8.9 in. x 6.3 in. x 4.5 in. (220 mm x 160 mm x 115 mm) |
| Weight | |
| BM15 | Approx 2.6 lbs (1.2 kg) |
| MJ15 | Approx 3.5 lbs (1.6 kg), or 4 lbs (1.8 kg) with battery holder and cells. |
