An AUTO selection option ensures that the most effective parameters are selected depending on the range required, aiding rapid diagnosis of the TDR trace. The ability to manually override the auto function allows fine tuning to enable identification of hard to determine faults.
Dual trace and dual cursor capabilities allow full flexibility, giving the operator full control and instant indication of distance between two points.
A trace comparison feature allows close examination between trace conditions. Extra high resolution together with a white-light backlight, user definable tones and color give the graphically display a vibrance, aiding the user in identifying key events on the trace.
Features
Benefits
Applications
| Accuracy | ±1% of range ±1 pixel at 0.67 VF |
| Resolution | 1% of range |
| Output Pulse | Up to 20 volts peak to peak into open circuit. Pulse widths determined by range and cable |
| Gain | Set for each range with user selectable steps (in Manual operating mode) |
| Velocity Factor | Variable from 0.2 to 0.99 in steps of 0.01 |
| TX Null | Automatic |
| Power Down | User programmable auto power off timer 1, 5, 10 mins or never |
| Battery | Li-ion rechargeable battery |
| Battery Charge Time | 6 hours at 0 to 40 °C |
| Battery Life | 12 hours typical |
| Case | ABS |
| Dimensions | 290 mm (11.4 in) x 190 mm (7.5 inches) x 55 mm (2.2 inches) |
| Weight | 1.7kg |
| Connectors | Four 4mm-safety terminals and two F connectors. Other standard push on adapters will fit the TDR20xx series |
| Test Lead | 1.5 metres long consisting of 2 x 4mm shrouded connector to miniature crocodile clips (TDR2000/3 and TDR2010) or 1.5 metre fused leads (TDR2000/3P) |
| Display | 800 x 480 pixel colour graphics LCD, viewable in external environments |
| Operating Temperaturerange and Humidity | -15 to +50 °C (5 to 122 °F) |
| Accuracy | ±1% of range ±1 pixel at 0.67 VF |
| Resolution | 1% of range |
| Output Pulse | Up to 20 volts peak to peak into open circuit. Pulse widths determined by range and cable |
| Gain | Set for each range with user selectable steps (in Manual operating mode) |
| Velocity Factor | Variable from 0.2 to 0.99 in steps of 0.01 |
| TX Null | Automatic |
| Power Down | User programmable auto power off timer 1, 5, 10 mins or never |
| Battery | Li-ion rechargeable battery |
| Battery Charge Time | 6 hours at 0 to 40 °C |
| Battery Life | 12 hours typical |
| Case | ABS |
| Dimensions | 290 mm (11.4 in) x 190 mm (7.5 inches) x 55 mm (2.2 inches) |
| Weight | 1.7kg |
| Connectors | Four 4mm-safety terminals and two F connectors. Other standard push on adapters will fit the TDR20xx series |
| Test Lead | 1.5 metres long consisting of 2 x 4mm shrouded connector to miniature crocodile clips (TDR2000/3 and TDR2010) or 1.5 metre fused leads (TDR2000/3P) |
| Display | 800 x 480 pixel colour graphics LCD, viewable in external environments |
| Operating Temperaturerange and Humidity | -15 to +50 °C (5 to 122 °F) |
| Accuracy | ±1% of range ±1 pixel at 0.67 VF |
| Resolution | 1% of range |
| Output Pulse | Up to 20 volts peak to peak into open circuit. Pulse widths determined by range and cable |
| Gain | Set for each range with user selectable steps (in Manual operating mode) |
| Velocity Factor | Variable from 0.2 to 0.99 in steps of 0.01 |
| TX Null | Automatic |
| Power Down | User programmable auto power off timer 1, 5, 10 mins or never |
| Battery | Li-ion rechargeable battery |
| Battery Charge Time | 6 hours at 0 to 40 °C |
| Battery Life | 12 hours typical |
| Case | ABS |
| Dimensions | 290 mm (11.4 in) x 190 mm (7.5 inches) x 55 mm (2.2 inches) |
| Weight | 1.7kg |
| Connectors | Four 4mm-safety terminals and two F connectors. Other standard push on adapters will fit the TDR20xx series |
| Test Lead | 1.5 metres long consisting of 2 x 4mm shrouded connector to miniature crocodile clips (TDR2000/3 and TDR2010) or 1.5 metre fused leads (TDR2000/3P) |
| Display | 800 x 480 pixel colour graphics LCD, viewable in external environments |
| Operating Temperaturerange and Humidity | -15 to +50 °C (5 to 122 °F) |
