Mitutoyo 178-561-12A Sj-210 Portable Surftest Standard Drive 4Mn

No reviews yet Write a Review
$2,934.51
SKU:
178-561-12A
Condition:
New
Availability:
In Stock
5 customers are viewing this product

Mitutoyo 178-561-12A Sj-210 Portable Surftest Standard Drive 4Mn

$2,934.51

Mitutoyo (178-561-12A) Surftest SJ-210 Portable Surface Roughness Tester, 4 mN

Mitutoyo SJ-210 Description

Highly versatile and delivers accurate measurements at high speeds, this surface roughness tester is full of features and capabilities that enhance productivity.

Features

  • Built-in 2.4" color graphic, back-lit LCD provides excellent readability, improved visibility and is easy-to-use in dark environments
  • The operation keys on the front of the unit and under the sliding cover are well-labeled and easy to use
  • Internal memory stores up to 10 measurement conditions and one measured profile
  • Password protection prevents unintended operations and protects instrument settings
  • The display interface supports 16 interchangeable languages
  • LCD display mode can be freely switched between portrait and landscape as well as left-hand or right-hand direction
  • High-speed USB communication: Data can be transferred to and from a computer via the high-speed USB interface
  • Memory card support: The memory card slot lets you store large amounts of data onto a memory card
  • Drive unit can be separated from the display unit by using a cable, allowing more flexible measurement, and can be separated and reattached in one simple step
  • The user-friendly screen layout and arrow keys provide intuitive operability
  • Displayed settings can be changed easily by using the left and right arrow keys
  • Infrequently used keys are hidden under the sliding cover to prevent unintended operations
  • Complies with the following standards: JIS (JIS-B0601-2001, JIS-B0601-1994, JIS B0601-1982), VDA, ISO-1997, and ANSI

Extensive display features that assist measurement

  • The highly visible 2.4" color graphic LCD with backlight lets you view the screen easily even in dark environments
  • Pass/fail results are displayed in color
  • Assessed profiles, load curves, and amplitude distribution curves can be displayed in addition to calculation results
  • Assessed profiles can also be zoomed up and down
  • The display mode can be easily switched between portrait and landscape
  • Calculation results are displayed in large characters

Advanced data storage capabilities

Up to 10 measurement conditions can be stored in the internal memory. Conditions can be quickly read according to the workpiece.

Stylus alarm function

An alarm warns you when the cumulative measurement distance exceeds a preset limit. This feature can be used to prevent problems that would be caused by worn out styli. Any value can be specified as the limit.

Easy setting

Displayed settings can be easily changed by pressing the left and right arrow keys under the sliding cover. For example, these keys can be used to switch the cut-off value (λc) and the number of sampling lengths (N) on the measurement screen.

Setting parameters and recalculating results

The required parameters can be selected from the screen. The sub-menu also lets you specify detailed settings such as the tolerance. After completing measurement, the parameters can be changed and calculation can be executed again using the new parameters.

Mitutoyo SJ-210 Specifications

Measuring Range X axis: 0.63" (16 mm)

Z axis (detector)
Range: 14400 µin (-7900 to 6300 µin) [360 µm (-200 to 160 µm)]
Range/resolution: 14400/0.8 µin (360/0.02 µm); 4000/0.2 µin (100/0.006 µm); 1000/0.08 µin (25/0.002 µm)
Measuring Speed When measuring: 0.01, 0.02, 0.03 in/s (0.25, 0.5, 0.75 mm/s)
When returning: 04 in/s (1 mm/s)
Measuring Force/Stylus tip 4 mN/5 μmR 90°
Skid Force Less than 400 mN
Applicable Standards JIS '82/JIS '94/JIS '01/ISO '97/ANSI/VDA
Assessed Profiles Primary profile, roughness profile, DF profile, roughness profile-Motif
Parameters Ra, Rc, Ry, Rz, Rq, Rt, Rmax, Rp, Rv, R3z, Rsk, Rku, Rc, RPc, Rsm, Rz1max, S, HSC, RzJIS, Rppi, RΔa, RΔq, Rlr, Rmr, Rmr(c), Rδc, Rk, Rpk, Rvk, Mr1, Mr2, A1, A2, Vo, Rpm, tp, Htp, R, Rx, AR, Possible Customize
Graph Analysis Bearing area curve/Amplitude distribution curve
Filters Gaussian, 2CR75, PC75
Cut Off Length λc: 0.003, 0.01, 0.03, 0.1" (0.08, 0.25, 0.8, 2.5 mm)
λs: 100, 300 µin (2.5, 8 µm)
Sampling Length 0.003, 0.01, 0.03, 0.1" (0.08, 0.25, 0.8, 2.5 mm)
Number of Sampling Lengths x1, x2, x3, x4, x5, x6, x7, x8, x9, x10
Arbitrary 0.01 to 0.63" (0.0001" interval) [(0.3 to 16 mm: 0.01 mm interval)]
LCD 1.45 x 1.93" (36.7 x 48.9 mm)
Display Languages Japanese, English, German, French, Italian, Spanish, Portuguese, Korean, Traditional Chinese, Simplified Chinese, Czech, Polish, Hungarian, Turkish, Swedish, Dutch
Measurement Result Display Vertical: 1-parameter display/3-parameter display/Trace display
Horizontal: 1-parameter display/4-parameter display/Trace display (invertable)
External I/O USB I/F, Digimatic Output, Printer Output, RS-232C I/F, Foot SW I/F
Functions Customization: Desired parameters can be selected for calculation and display
GO/NG judgment: By maximum value/16 %/Standard deviation
Storage of measurement condition: Save the conditions at power OFF
Storage: Internal memory: Measurement condition (10 sets)
Calibration: Auto-calibration with the entry of numerical value/average calibration with multiple measurement (maximum 5 times) is available
Power-saving Function Auto-sleep off function (10 to 600 seconds)
Power Supply Two-way power supply: battery (rechargeable Ni-MH battery) and AC adapter
Charging time: about 4 hours (may vary due to ambient temperature)
Endurance: about 1000 measurements (differs slightly due to use conditions/environment)
Dimensions Disply unit: 2.05 x 2.6 x 6.3" (52.1 x 65.8 x 160 mm), sliding cover closed, detector not mounted
Drive unit: 4.5 x .9 x 1.02" (115 x 23 x 26 mm), detector not mounted
Weight About 1.1 lbs (500 g)

Applications

  • Aerospace
  • Automative
  • Defense
  • Energy
  • General manufacturing
  • Medical
