Winters P3S6035, 300 SERIES 4.5" 0-60 PSI/KPA 1/4" SS ,Digital Pressure Guage

No reviews yet Write a Review
$278.58
12 sold in last 36 hour
SKU:
P3S6035
UPC:
628311282610
Condition:
New
Availability:
In Stock
5 customers are viewing this product

Winters P3S6035, 300 SERIES 4.5" 0-60 PSI/KPA 1/4" SS ,Digital Pressure Guage

$278.58

Description:

Intended for non-clogging installations. Use on air, steam, oil, fresh water. Boilers, control rooms and chillers.

Features:

  • Heavy duty, highly accurate aluminum case gauge
  • ±0.5% accuracy
  • Brass or stainless steel internals
  • Large, easy-to-read dial
  • StabiliZR dampened movement available on 4.5" (115mm) dial size
  • ASME B40.100 compliant

Specification

Pressure Range0/60 psi/kPa
Dial4.5" (115mm) white aluminum with black and red markings
CaseAluminum painted black
Front FlangeSS, polished
Back FlangeSteel, painted black (optional)
LensGlass
RingSS, polished
Socket316L SS
Connection1/4" NPT
Bourdon Tube316L SS
Movement304 SS
PointerAluminum, anodized black, micrometer adjustable
Welding316L SS TIG Argonarc
Over-pressure Limit30%
Working PressureMaximum 75% of full scale value
Ambient/Process Temperature-40°F to 150°F (-40°C to 65°C)
Accuracy±0.5% ANSI/ASME Grade 2A
Enclosure RatingIP52
