Winters PFQ911ZR, 2.5"x 1/4" NPT BACK, 0-3,000 PSI/KPA,

No reviews yet Write a Review
$75.77
SKU:
PFQ911ZR
UPC:
628311238877
Condition:
New
Availability:
In Stock
5 customers are viewing this product

Winters PFQ911ZR, 2.5"x 1/4" NPT BACK, 0-3,000 PSI/KPA,

$75.77
  • Pulsation resistant, liquid filled stainless steel case
  • Glycerin filled standard
  • Brass, lead free brass or stainless steel internals
  • Restricted orifice standard on dual scale
  • Ventable plug on 2.5″ (63mm) and 4″ (100mm) bottom mount (excluding SAE connection)
  • Crimp-On bezel
  • Single (psi) or dual scale (psi/kPa)/(psi/bar) available
  • Optional U-Clamps and front flanges
  • Dry case available
  • ASME B40.100 compliant
  • RoHS compliant (SS internals only)
  • CRN registered
  • Lead free version NSF-61-372 certified also available with LF indicated
  • PSI Gauges are useful instruments used for measuring fluid, gas, water, or steam intensity in a pressure system. If you’re looking for a psi gauge, look no further! We offer some of the top performing psi gauges in the market.

APPLICATIONS:

  • Ideal for pumps, compressors, hydraulic presses, machinery, pneumatic equipment and motors in harsh environments

Note: The image may be different from the actual product

General Specifications for PFQ series

Dial 1.5″ (40mm), 2″ (50mm), 2.5″ (63mm), 4″ (100mm), white aluminum with black and red markings
Case AISI 304 SS
Lens Polycarbonate
Ring AISI 304 SS, Crimp-On
Socket

PFQ: OT 58 brass with restricted orifice (dual scale only) or AISI 316 SS with restrictor screw (dual scale only)

PFQ-LF: Lead free brass with restricted orifice (dual scale only), NSF-61-372 certified

Connection 1/8”, 1/4” or 1/2” NPT standard with restricted orifice
Fill Liquid Glycerin
Bourdon Tube

1.5” (40mm), 2″ (50mm): Phosphor bronze C or coil shaped for brass socket SS C or coil shaped for 316 SS socket

2.5” (63mm), 4” (100mm): Phosphor bronze C or coil shaped, AISI 316 SS C or coil shaped for 316 SS socket

Movement

PFQ: OT 59 brass or SS

PFQ-LF: Lead free brass, NSF-61-372 certified

Pointer Aluminum, anodized black
Welding

Brass: Silver alloy,

316SS: TIG

Over-pressure Limit

25% for pressures up to 1,450 psi (9,998 kPa)

15% for pressures over 1,450 psi (9,998 kPa)

Socket Material  Buna N for two-piece internal socket seal
Fill Plug Buna N
Lens Ring Gasket Silicone rubber
Working Pressure Maximum 75% of full scale value
Ambient/Process Temperature

Dry: -40°F to 200°F (-40°C to 93°C)

Glycerin Filled: -4°F to 150°F (-20°C to 65°C)

Accuracy

1.5” (40mm), 2″ (50mm): ±2.5% of full scale

2.5” (63mm), 4” (100mm): ±1.5% of full scale value

Enclosure Rating IP65
Warning (brass and lead free brass internals only) Warning: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov.
