Winters PTR5073R1, TAMPER RESISTANT GAUGE 4.5" 0-3000 PSI Only 1/2" NPT ST/ST,

No reviews yet Write a Review
$740.42
SKU:
PTR5073R1
UPC:
628311297126
Condition:
New
Availability:
In Stock
5 customers are viewing this product

Winters PTR5073R1, TAMPER RESISTANT GAUGE 4.5" 0-3000 PSI Only 1/2" NPT ST/ST,

$740.42

Description:

Winters, PTR5073R1, PTR 4.5" 0/3,000 PSI, 1/2" NPTM SS Tamper Resistant Process Gauge

Features:

  • Solid front, pressure relief back, welded to a 316L stainless steel one-piece diaphragm seal body
  • 316L stainless steel diaphragm for use on most corrosive media
  • Permanently enclosed silicone filled system
  • Field-fillable gauge
  • Orifice restrictor available for severe pulsation
  • Pin stop at 6 o’clock available
  • ASME B 40.100 compliant
  • CRN registered
  • 5 year warranty on gauge, 1 year warranty on seal

Applications:

  • Process industry where tamper-resistant gauge/seal is required to protect against maintenance errors in the field

Specification

Gauge
Pressure Range0/3,000 PSI
Dial4.5" (115mm) white aluminum with black and red markings
CaseBlack phenolic with pressure relief back, solid front, integral back flange
Solid WallPhenolic
Pressure Relief BackPolypropylene
WindowPolypropylene
RingPhenolic
PointerAluminum, anodized black, micrometer adjustable
Socket316L SS
Bourdon Tube316L SS, drawn seamless
Gasket MaterialsSilicone (Viton® option)
WeldingTIG
Over-pressure Limit25% for pressures up to 1,450 PSI (9,998 kPa), 15% for pressures 1,451 PSI to 5,000 PSI (9,998 kPa to 34,474 kPa)
Working PressureMaximum 75% of full scale value
Ambient TemperatureDry: -40°F to 250°F (-40°C to 120°C)
Process TemperatureSilicone Filled: -49°F to 302°F (-45°C to 150°C)
Movement±1% ANSI/ASME Grade A
AccuracyAluminum, anodized black, micrometer adjustable
Enclosure RatingIP65
Seal
HousingAISI 316 SS
DiaphragmAISI 316L SS, welded
Minimum Operating Pressure15 PSI (103 kPa)
Maximum Operating Pressure2,500 PSI to 5,000 PSI (17,237 kPa to 34,474 kPa)
Process Connection1/2" NPTM
System FillSilicone oil KF96 50CS
