AEMC 5212 True RMS Multimeter, 4000 counts, 600V AC/DC

Availability: 2 to 3 Weeks

AEMC Instruments 5212 Offers

Compact and simple to use, these multimeters with a large backlit display and non-contact voltage detection are exceptional products and a great value for today's market. Measurement features include Auto Range mode, which enables the instrument to select the best range for the input detected, and a Data HOLD function. This instrument is rugged and simple to use and rated to 600V CAT III.

Features

• Non-contact detection of network AC voltage
• High sensitivity with a resolution of 0.01mV
• Their protection enables them to withstand overloads up to 8000V
• VLowZfunction detect the presence of ghost voltage by placing a burden on the circuit
• Multi-position mounting
• Battery life extended with "sleep mode" feature
• Backlight screen and flashlight

Applications

• Measurement of electrical values including: voltage, resistance and capacitance
• Continuity checking
• Diode testing
• Non-contact detection of network voltage

AEMC Instruments 5212 Specifications

Specifications

AC Bandwidth	1000kHz
Auto/Manual Ranging	Yes
Voltage AC/DC	600V
Current AC/DC	4A/10A
µAmps AC/DC	400/4000µA
Resistance	40MΩ
Capacitance	100mF
Continuity with Beeper	Yes
Diode Test	Yes
V Low Z	Yes
Non Contact Voltage Detection (NCV)	Red display with buzzer
Max / Min / Max-Min Functions	No
REL Function	No

What's included with the AEMC Instruments 5212

• AEMC 5212 Digital Multimeter
• Set of 2 color-coded leads, red and black
• Soft Carrying Pouch
• 2 x 1.5V AA batteries
• User Manual

AEMC 5212 True RMS Multimeter, 4000 counts, 600V AC/DC. Great savings and get fast delivery when you order online at EquipTestPro.com.
