AEMC MN05 AC Current Probe, 5 mA to 10 AAC, 1 to 100 AAC

Availability: 9 to 10 Weeks

AEMC Instruments MN05 Offers

Features

• Measurements from 5 mA to 10 AAC and 1 to 100 AAC
• Permits very low AC current measurements
• "Clothes pin" shape makes them ideal for use in tight areas, such as breaker panels, controller panels or outlets
• Jaw opening accommodates conductors up to 0.39" diameter
• 600 V CAT III safety rating
• Double insulation
• CE Mark

Applications

• Low-power secondary transformers
• Industrial

AEMC Instruments MN05 Specifications

Specifications

Nominal Range	10; 100 AAC
Measurement Range	5 mA to 10 AAC1 to 100 AAC
Transformation Ratio	Voltage output
Output Signal	1 mV/mA, 1 mV/A (10 VAC at 10 A, 100 mVAC at 100 A)
Overload	10 A range: 15 A100 A range: 150 A
Frequency Range	48 to 500 Hz
Load Impedance	≥1 MΩ
Output Termination	5' (1.5 m) lead with two 4 mm safety banana plugs
Temperature	Operating: 14 to 122°F (-10 to 50°C)Storage: -40 to 176°F (-40 to 80°C)
Operating Relative Humidity	0 to 85% RH decreasing linearly above 95°F (35°C)
Safety Rating	IEC 61010-2-32: 300 V CAT IV, 600 V CAT III, Pollution Degree 2
Ingress Protection	IP40
Double Insulation	Yes
CE Mark	Yes
Material	Polycarbonate UL 94 V2
Maximum Conductor Size	ø0.39" (10 mm)
Dimensions	5.12 x 1.5 x 1" (130 x 37 x 25 mm)
Weight	6.35 oz (180 g)

What's included with the AEMC Instruments MN05

• AEMC MN05 AC Current Probe, 5 mA to 10 AAC, 1 to 100 AAC
