Features
Applications
| Numbers of Channels | 2 Isolated channels |
| Bandwidth | 100 MHz |
| Input Impedance | 1 MΩ ±0.5%, approx. 12 pF |
| Vertical | |
| Vertical Sensitivity | 16 ranges from 2.5 mV - 200 V/div and up to 156 μV/div on vertical zoom mode (12-bit converter) - Accuracy ±2% |
| Maximum Input Voltage | 600 V/CAT III (1000 V per Probix) - from 50 to 400 Hz - Probix connectors |
| Vertical Zoom | "One click Winzoom" system (direct graphical zoom onscreen) x 16 max |
| Horizontal | |
| Time Base Speed | 35 ranges from 1 ns/div. - accuracy ±[50 ppm + 500 ps] - Roll mode from 100 ms to 200 s/div |
| Horizontal Zoom | "One click Winzoom" system (direct graphical zoom onscreen) x 100 max |
| Trigger | |
| Mode | Auto, triggered, one-shot, auto-level 50% on all channels |
| Type | Edge, Pulse width (16 ns to 20 s), delay (48 ns to 20 s), counting (3 to 16,384 events)Continuous adjustment of trigger position |
| Digital Memory | |
| Maximum Sampling Rate | 2.5GS/s in one-shot mode on each channel (100GS/s max. in ETS mode) 12 bits resolution |
| Memory Depth | 100 kpts per channel and file viewer in the manager |
| Other Functions | |
| FFT Analyzer & Math Functions | FFT (Lin or Log) with measurement cursors - Functions, +, - x, / and mathematical function editor |
| Multimeter Mode | 2 channels, 8000 counts + Min/Max/Frequency/relative - TRMS - Time stamp graphic recording in logger mode |
| Harmonic Analyzer Mode | Multi-channel analysis: 2, 61 orders, fundamental from 40 to 450 Hz in auto or manual modeSimultaneous measurement: Total Vrms, THD and selected order (% fundamental, phase, frequency, Vrms) |
