Dwyer RMA-7-TMV Flow Meter, 2" Scale, 5-50 SCFH Air, Top Mounted Valve

No reviews yet Write a Review
$96.81
5 sold in last 12 hour
SKU:
RMA-7-TMV
Condition:
New
Availability:
In Stock
5 customers are viewing this product

Dwyer RMA-7-TMV Flow Meter, 2" Scale, 5-50 SCFH Air, Top Mounted Valve

$96.81

Dwyer RM Series

Features

  • Easy to read design - The direct reading scales eliminate troublesome conversions
  • Special integral flow guides stabilize the float throughout the range to keep it from hunting or wandering in the bore
  • The float is highly visible against a white background
  • Construction assures accuracy - All Rate-Master flowmeter bodies are injection moulded of tough, clear, shatter-proof polycarbonate plastic around a precision tapered pin
  • The result is accurate and repeatable readings
  • The single piece plastic body is mounted to a stainless steel back bone into which pipe thread inserts are welded to absorb piping torque
  • Precision metering valves of brass or stainless steel (specify BV or SSV on order) are available as an optional extra and permit precise flow adjustments
  • For vacuum applications, Model RMA units are available with top mounted valves (specify TMV in the model number)
  • Installation is simple - The Rate-Master flowmeter can be neatly through-panel mounted to keep flow tube centres in the same plane as the panel surface or surface mounted on the panel by means of tapped holes in the backbone
  • When through-panel mounted, the bezel automatically positions the instrument at the correct depth in the panel cutout
  • Surface mounted units can also be held in place by the piping
  • All mounting hardware plus installation and operating instructions are included
  • Easy-to-Interchange bodies - Within a given Series Rate-Master flowmeter bodies can be instantly interchanged
  • Simply "unplug" the body from backbone and replace it with another
  • O-rings provide a tight seal on inlet and outlet
  • Piping remains undisturbed
  • Interchangeability is useful where different scale ranges are sometimes required at the same location in the laboratory or plant
  • Cleaning is easy - To release the plastic flowmeter body from the stainless steel backbone, just remove four screws
  • Pipe thread flow connections remain undisturbed
  • Remove the slide cover and the plug ball stop, clean the flow tube with soap and water and reassemble

Dwyer RMA-7-TMV Specifications

Service Compatible gases and liquids
Wetted Materials Body: Polycarbonate
O-ring: Neoprene and Buna-N
Metal parts: stainless steel (except for optional brass valve)
Float: stainless steel, black glass, aluminum, K monel, tungsten carbide depending on range
Temperature Limit 130°F (54°C)
Pressure Limit 100 psi (6.9 bar)
Accuracy RMA: 4%
RMB: 3%
RMC: 2% of full scale
Process Connection RMA: 1/8"
RMB: 1/4"
RMC: 1/2" female NPT
Weight RMA: 4 oz (113.4 g)
RMB: 13 oz (368.5 g)
RMC: 39 oz (1105.6 g)
