Hioki 8971 Memory HiCorder Current Module, DC/30Hz to 10kHz
SKU: 8971
Availability: 2 to 3 Weeks Hioki 8971 Offers Easily connect this Hioki 8971 Memory HiCorder Current Module to your Memory HiCorder and current sensors. The module features a wide-bandwidth RMS rectifier installed to measure DC and 30 Hz to 10 kHz current waveforms. Features Measures wide-band current waveforms instantly Can be directly connected to current sensors (sold separately) Equipped with a wide-bandwidth RMS rectifier for measuring low
Availability: 2 to 3 Weeks
Hioki 8971 Offers
Easily connect this Hioki 8971 Memory HiCorder Current Module to your Memory HiCorder and current sensors. The module features a wide-bandwidth RMS rectifier installed to measure DC and 30 Hz to 10 kHz current waveforms.
Features
- Measures wide-band current waveforms instantly
- Can be directly connected to current sensors (sold separately)
- Equipped with a wide-bandwidth RMS rectifier for measuring low to high frequencies, such as DC and 30 Hz to 10 kHz
- Allows you to monitor instantaneous waveforms without having to pass through a rectifying circuit
- Boasts 12-bit A/D resolution
- Compatible with Memory HiCorder MR6000, MR8847A, MR8827 and similar models (sold separately)
Hioki 8971 Specifications
Specifications
| Number of Channels | 2 |
| Input Connectors | Sensor (1 MΩ input impedance, exclusive connector for current sensor via the 9318 conversion cable, common ground with recorder) |
| Compatible Current Sensors | CT6863, CT6862, 9709, 9279, 9278, 9277, 9272-10 (to connect the 8971 via the 9318 conversion cable) |
| Measurement Range | 20 A, 200 A (9272-10 sensor), 100 mA to 5 A/div (9277 sensor), 200 mA to 10 A/div (CT6862 sensor), 1 A to 50 A/div (9278, CT6863 sensors), 2 A to 100 A/div (9279, 9709 sensors) |
| Measurement Resolution | 1/100 of range |
| Highest Sampling Rate | 1 MS/s (simultaneous sampling across 2 channels) |
| Input Coupling | AC, DC, ground |
| Low-Pass Filter | 5/50/500 Hz, 5/50 kHz, Off |
| RMS Amplitude Accuracy | ±1% f.s. (DC, 30 Hz to 1 kHz), ±3% f.s. (1 kHz to 10 kHz) |
| RMS Response Time | 100 ms (rise time from 0 to 90% of full scale) |
| Crest Factor | 2 |
| Frequency Characteristics | DC to 100 kHz, ±3 dB, 7 Hz to 100 kHz (with AC coupling) |
| Accuracy | ±0.85% f.s. (9278, 9279), ±0.65% f.s. (other sensors) |
| CE Compliant | Yes |
| Product Length | 7.74" (196.5 mm) |
| Product Width | 4.17" (106 mm) |
| Product Height | 0.78" (19.8 mm) |
| Product Weight | 8.8 oz (250 g) |
| Manufacturer Warranty | 3 years |
What's included with the Hioki 8971
- Current Module
- 2 x 9318 Conversion Cables
