Hioki 9675 Clamp-On Voltage Output Leak Current Sensor, 10A AC
SKU: 9675
Availability: Regular Price Hioki 9675 Offers When you connect this Hioki 9675 Clamp-On Voltage Output Leak Current Sensor to your Hioki 3169, 3197, LR5051 or PW3198 device (sold separately), you’ll be able to measure leak current up to 10A AC. The clamp-on design provides safe and easy attachment to wires. Features Compatible with Hioki 3169, 3197, LR5051 and PW3198 models (sold separately) Captures leak current up to 10A AC Features a highly
Availability: Regular Price
Hioki 9675 Offers
When you connect this Hioki 9675 Clamp-On Voltage Output Leak Current Sensor to your Hioki 3169, 3197, LR5051 or PW3198 device (sold separately), you'll be able to measure leak current up to 10A AC. The clamp-on design provides safe and easy attachment to wires.
Features
- Compatible with Hioki 3169, 3197, LR5051 and PW3198 models (sold separately)
- Captures leak current up to 10A AC
- Features a highly permeable magnetic sensor core and a magnetic shield to provide precise measurements of weak currents
- Clamp-on design with a φ1.18in (30mm) core diameter allows simple attachment to wires
- 9.84ft (3m) cord length offers a flexible reach
Hioki 9675 Specifications
Specifications
| Compatibility | Hioki 3169, 3197, LR5051 and PW3198 models |
| Rated Primary Current | 10A AC (for leak current measurement, 50/60Hz) |
| Maximum Allowable Input | 10A continuous (45 to 66Hz) |
| Rated Output Current | 100mV/A AC |
| Amplitude Accuracy | ±1% of reading, ±0.005% of full scale |
| Phase Accuracy | ±5° (at 50 or 60Hz) |
| Frequency | 40Hz to 5kHz ±5% |
| Core Diameter | φ1.18in (30mm) |
| CE Compliant | Yes |
| Product Length | 0.93in (23.6mm) unit, 9.84ft (3m) cord |
| Product Width | 2.36in (60mm) |
| Product Height | 4.43in (112.5mm) |
| Product Weight | 5.6oz (160g) |
What's included with the Hioki 9675
- Leak Current Sensor
- Instruction Manual
