Hioki CM3286-50 AC Clamp Power Meter

Availability: Regular Price

Hioki CM3286-50 Offers

Features

• Measure voltage, current, power, power factor, phase angle, reactive power or frequency
• Detect phase sequence on live lines at any desired point of a single-phase circuit or three-phase circuit
• Safely and accurately measuring power lines
• Display four parameters simultaneously
• A handheld power meter that measures from 5 W of power and 60 mA of current measure power ranging from 5 W at a low current of 60 mA to 360 kW
• Delivers fast and efficient testing

Hioki CM3286-50 Specifications

Specifications

Measurement Line	Single-phase, Three-phase (should be balanced and no distortion)
Measurement Items	Voltage, Current, Voltage/current peak, Active/reactive/apparent power, Power factor, Phase angle, Reactivity, Frequency, Simple Active Energy Consumption (Single-phase)
AC Voltage	Measurement range: 80 to 600 V, Single rangeBasic accuracy 45 to 66 Hz: ±0.7% rdg. ±3 dgt.Frequency characteristics: 45 Hz to 1 kHz, True RMS
AC Current	Measurement range: 0.060 to 600 A, 3 rangeBasic accuracy 45 to 66 Hz: ±1.3% rdg. ±3 dgt.Frequency characteristics: 45 Hz to 1 kHz, True RMS
Power	Single phase: 0.005 to 360 kW; Basic accuracy: ±2.0% rdg. ±7 dgt. (50/ 60 Hz, Power factor= 1)Balanced three-phase 3-wire: 0.020 to 623.5 kW; Basic accuracy: ±3.0% rdg. ±10 dgt. (50/ 60 Hz, Power factor= 1)Balanced three-phase 4-wire: 0.040 to 1080 kW; Basic accuracy: ±2.0% rdg. ±3 dgt. (50/ 60 Hz, Power factor= 1)
Maximum Rated Voltage to Earth	600V AC (Measurement category IV)1000 V AC (Measurement category III)
Crest Factor	6 A/60 A range 3 or less, 600 A/600 V range 1.6 or less
Operating Temperature	-13 to 149°F (-25 to 65°C or less)
Storage Temperature	-13 to 149°F (-25 to 65°C or less)
Dustproof and Waterproof	Grip: IP54 (EN60529), Jaw: IP50 (EN60529)
Standards	Safety: EN61010, EMC: EN61326
Power Supply	2 x LR03 Alkaline batteries
Continuous Use	Approx. 25 hours (Backlight off)
Core Jaw Diameter	Ø 1.81" (46 mm)
Dimensions	3.23 x 9.49 x 1.46" (82 x 241 x 37 mm)
Weight	15.9 oz (450 g)

What's included with the Hioki CM3286-50

• Clamp Meter
• 2 x Alkaline Batteries
• Instruction Manual
• Connection Cord
• Carrying Case
