Hioki CM4371 AC/DC True RMS Clamp Meter, 600 A

Availability: Regular Price

Hioki CM4371-90 Offers

This Hioki CM4371 AC/DC True RMS Clamp Meter is designed to measure AC voltage up to 1,000 V and DC voltage up to 1,700 V, as well as AC/DC current up to 600 A. The dustproof and waterproof enclosure adds to the durability. Plus, you can measure inrush current in RMS and crest values simultaneously.

Features

• Ideal for the development, repair and maintenance of equipment and devices, including electric vehicles
• Performs a variety of measurement functions
• Capable of measuring DC voltages up to 1,700 V and AC voltages up to 1,000 V, as well as AC/DC current from 20 to 600 A
• Tests resistance from 600 Ω to 600k Ω and a frequency range of 9.999 to 999.9 Hz
• Features an IP54 dustproof and waterproof enclosure and IP50-rated jaws
• Use the auto hold feature to freeze the results on the display until the next measurement starts
• Can detect the full startup current period and identify the RMS waveform
• Notifies you with a buzzer and red LED if a short circuit is detected
• Additional functions include plus/minus judgment function of DC A and DC V, max/min/average/peak max/peak min value display, filter, auto power save and zero adjustment

Hioki CM4371-90 Specifications

Specifications

AC Current	20/600 A (10 Hz to 1 kHz, True RMS) with ±1.3% of reading ±0.08 A (at 20 A) accuracy
DC Current	20/600 A with ±1.3% of reading ±0.08 A (20 A range) accuracy
AC + DC Current	20/600 A (10 Hz to 1 kHz, True RMS) with ±1.3% of reading ±0.13 A (at 20 A) accuracy
AC Voltage	6 to 1,000 V in 4 ranges (15 Hz to 1 kHz, True RMS) with ±0.9% of reading ±3 digits accuracy
DC Voltage	600 mV to 1,500 V in 5 ranges with ±0.5% of reading ±3 digits accuracy
AC + DC Voltage	6 to 1,000 V in 4 ranges with ±1.0% of reading ±7 digits accuracy
Crest Factor	20 A range: 7.5, 600 A range: 3 or less
Resistance	600 Ω to 600k Ω in 4 ranges with ±0.7% of reading ±5 digits accuracy
Electrostatic Capacity	1 to 1,000 μF in 4 ranges with ±1.9% of reading ±5 digits accuracy
Frequency	9.999 to 999.9 Hz with ±0.1% of reading ±1 digit accuracy
Temperature	-40 to 752°F (-40 to 400°C) with ±0.5% of reading ±3°C accuracy (plus temperature probe accuracy)
Voltage Detection	High: 40 to 600 VAC, low: 80 to 600 VAC, 50/60 Hz
Other Functions	Automatic AC/DC detection, plus/minus judgment function of DC A, DC V, max/min/average/peak max/peak min value display, filter function, display value hold, auto hold, backlight, auto power save, zero adjustment
IP Rating	Grip: IP54, jaw/barrier: IP50
Core Jaw Diameter	φ1.3" (33 mm), 2.72 x 0.55" (69 x 14 mm)
Product Length	1.38" (35 mm)
Product Width	2.56" (65 mm)
Product Height	8.46" (215 mm)
Product Weight	12 oz (340 g)
Manufacturer Warranty	3-year limited

What's included with the Hioki CM4371-90

• AC/DC Clamp Meter
• L9207-10 Test Lead
• C0203 Carrying Case
• 2 x LR03 Alkaline Batteries
• Instruction Manual
