Hioki CT6904 AC/DC Current Sensor with ME15W Terminal, 9.84' Cable

Availability: 2 to 3 Weeks

Hioki CT6904A Offers

When you need reliable signal capture, use the Hioki CT6904 AC/DC Current Sensor. It is ideal for use with oscilloscopes, power analyzers and more. Plus, this sensor comes with an ME15W terminal so you can connect it directly to your equipment. CE compliant with a 3-year warranty.

Features

• Handles high capacities of current for use in heavy-duty applications
• 120 dB (100 kHz) Common-Mode Rejection Ratio for confident operation
• Wide temperature range allows for use in many different settings
• High accuracy level instills confidence in your measurements
• Safely store and transport sensor in included carrying case
• Equipped for reliable frequency operation over wide range
• Attached cable with ME15W terminal provides extended reach and convenient connection

Applications

• Capturing current signals from switching power supplies
• Inverters and power conditioners

Hioki CT6904A Specifications

Specifications

Rated Current	500 A AC/DC
Maximum Allowable Input	550 A (however, up to ±1,000 Apeak (design value) allowed if within 20 ms)
Frequency Bandwidth	Amplitude: DC to 4 MHz; phase: DC to 1 MHz
Output Voltage Rate	4 mV/A rated (2 V rated current value)
Linearity/Offset Voltage	±10 ppm typical at 73°F (23°C)
Maximum Rated Power	7 VA maximum at 500 A/55 Hz with a power supply of ±12 V
Operating Temperature	14 to 122°F (-10 to 50°C), 80% RH or less (noncondensing)
Termination	ME15W
Compliance	CE
Product Length	2.05" (52 mm) depth; 9.84' (3 m) cable
Product Width	5.47" (139 mm)
Product Height	4.72" (120 mm)
Product Weight	35.3 oz (1 kg)
Manufacturer Warranty	3 years

What's included with the Hioki CT6904A

• Sensor
• Instruction Manual
• Carrying Case
• Color Labels
