Hioki LR5042 20 Voltage Logger

Availability: Regular Price

Hioki LR5042-20 Offers

• Easily mount the light-weight , pocket-sized loggers in tight spaces
• Easy-to-see dual display
• Transfer data to PC even during recording
• Replace batteries while recording(30 second limit)
• Record 60,000 data per channel
• Record without missing fluctuations in STAT mode
• Measurement data is preserved even after the battery dies
• Worry-free backup preserves recorded data even if a new measurement is started by mistake

Hioki LR5042-20 Specifications

Specifications

Measurement	Items: DC voltage 1 chRange: -50 to 50 mV
Accuracy	±0.5% rdg. ±5 digits
Storage Capacity	Instantaneous value mode: 60,000 dataStatistical value mode: 15,000 data
Recording	Interval: 1 to 30 seconds, 1 to 60 minutes, 15 selectionsModes:Instantaneous recording: At every recording intervalStatistical value recording: Measure at one second intervals, and record the instantaneous, maximum, minimum, and average values within every recording intervalMethods:One-time recording: Stop recording when the memory capacity is fullEndless recording: Continue recording even when the memory capacity is full (old data is overwritten)Start: Logger button operation or scheduled timeStop: Logger button operation or scheduled time, or auto-stop when the memory capacity is full (at one-time recording)
Other Functions	Pre-heat function (requires external power supply during use of function), always backs up last recorded data; backs up recorded data and setting conditions when battery power is low; guarantees approximately 30 seconds of recording operation and clock while battery is replaced
Waterproof and Dust-proof	IP54 (EN60529) (with connection cable connected, but not including cable tip)
Interfaces	Infrared optical communications with LR5091, LR5092-20
Power Supply	LR6 (AA) Alkaline batteryBattery life: Approxmately 2 years (instantaneous recording, with 1-minute interval and auto power saving, at 68°F [20°C]), approximately 2 months (Instantaneous recording, with 1-second interval at 68°F [20°C])
Dimensions	3.11 x 2.246 x 1.10" (79 x 57 x 28 mm)
Weight	3.7 oz (105 g)

What's included with the Hioki LR5042-20

• Voltage Logger
• Connection Cable
• Kickstand
• LR6 (AA) Alkaline Battery (Built-In Internal)
• Operation Guide
• Instruction Manual
