Hioki SP7001-90 Non-Contact CAN Signal Sensor
SKU: SP7002
$1,421.28
Availability: 2 to 3 Weeks Hioki SP7002 Offers Features Acquire CAN data immediately, simply by hooking probes to the cables Eliminates concerns by using non-contact sensing technology Use in a diverse array of development and evaluation applications that demand reliability Hioki SP7002 Specifications Specifications Detection Method Capacitive-coupled signal detection with no bare-wire connections Detectable Cables AVS/AVSS-compliant cables, e
Secure Checkout
Fast Shipping
Authorized Dealer
Availability: 2 to 3 Weeks
Hioki SP7002 Offers
Features
- Acquire CAN data immediately, simply by hooking probes to the cables
- Eliminates concerns by using non-contact sensing technology
- Use in a diverse array of development and evaluation applications that demand reliability
Hioki SP7002 Specifications
Specifications
| Detection Method | Capacitive-coupled signal detection with no bare-wire connections |
| Detectable Cables | AVS/AVSS-compliant cables, external diameter: 0.05" (1.2 mm) to 0.08" (2 mm) |
| Number of Channels | 2 (SP7100) |
| Compatible Communications Speeds | SP7001: CAN FD 125 kbit/s to 3 Mbit/s |
| Total Delay Time | 130 ns (typical) |
| CAN Terminal Resistance | 60 Ω (typical), built-in |
| Signal Output Connector | D-sub 9-pin female (CH1, CH2) |
| Operating Temperature, Humidity | Temperature: -40 to 85°C (-40 to 185°F)Humidity: -40 to 60°C (-40 to 140°F), 80% RH or less (with no condensation), 60 to 85°C (140 to 185°F), 60% RH or less (with no condensation) |
| Power Supply | (1) AC Adapter Z1008 (100 to 240 V AC), rated power: 8 VA (including AC adapter)(2) External power supply (10 to 30 V DC), rated power: 3 VA |
| Dimensions | SP7002: 1.73 x 3.35 x 0.79"(44 x 85 x 20 mm), Cable length: 8.20' (2.5 m) |
| Weight | SP7002: 180 g (6.3 oz) |
What's included with the Hioki SP7002
- Hioki SP7001-90 Non-Contact CAN Signal Sensor
Hioki SP7001-90 Non-Contact CAN Signal Sensor. Get Free Shipping when you order online at EquipTestPro.com.
