Hioki U8976 High-Speed Analog Unit for HiCorders, 5 MS/second

Availability: 2 to 3 Weeks

Hioki U8976 Offers

Pair the Hioki U8976 High-Speed Analog Unit for HiCorders with your model MR6000 (sold separately) to meet high-speed sampling demands. It conveniently accepts multiple inputs simultaneously for efficient data collection. Plus, it is CE-compliant with a 3-year warranty, giving you confidence that lasts.

Features

• Able to target and record high-speed phenomena with high-speed sampling
• Accepts 2 inputs for multi-channel efficiency
• High 12-bit resolution ensures maximum accuracy
• Flat, compact design for easy installation and unobtrusive operation
• Compatible with Hioki MR6000 Memory HiCorder (sold separately)
• Complies with major safety standards

Hioki U8976 Specifications

Specifications

Measurement	2 channels for voltage measurement
Measurement Range	12 ranges: 100, 200, 400 mV fs, 1, 2, 4 , 10, 20, 40, 100, 200, 400 V fs (AC voltage for possible measurement/display using the memory function: 280 V rms)
Input	Isolated BNC terminal
Measurement Resolution	1/1,600 of measurement range (using 12-bit A/D conversion)
Maximum Sampling Rate	200 MS/second (2-channel simultaneous sampling)
Measurement Accuracy	±0.5% fs (with filter 5 Hz, zero position accuracy included)
Input Coupling	AC/DC/GND
Maximum Allowable Input	400 V DC (when direct input), 1,000 V DC (when using the 9665)
Compatibility	Hioki MR6000 Memory HiCorder (sold separately)
Compliance	CE
Product Length	7.74" (196.5 mm) depth
Product Width	4.17" (106 mm)
Product Height	0.78" (19.8 mm)
Product Weight	9.9 oz (280 g)
Manufacturer Warranty	3 years

What's included with the Hioki U8976

• Hioki U8976 High-Speed Analog Unit for HiCorders, 5 MS/second
