Megger 1009667 HFCT SC40 HFCT Sensor, 40 mm

Availability: 2 to 3 Weeks

Megger HFCT SC40 Offers

Prevent propagation delay differences that diminish accuracy with the Teledyne LeCroy DCS025 Current and Voltage Probe Deskew Calibration Source. The voltage and current probe calibrator generates time-aligned pulses for precise performance. A large current loop allows wide-ranging use, and the low static skew is appropriately timed to match most probes.

Features

• Loop size is compatible with 30, 150 and 500 A current probes
• Supports standard and high-sensitivity probes, including CP030, CP030A, CP031, CP031A, AP015, CP150 and CP500
• Generates time-aligned 5 V and 100 mA voltage and current pulses to ensure precise deskewing
• Connect a voltage probe to the voltage pulse signal and ground connection and a current probe to the current pulse loop to measure and manually deskew propagation delay differences via a compatible oscilloscope's channel setup dialog
• Channel acquisition averaging supports output current amplitude measurement with higher amperage current probes
• 1 ns internal static skew provides an ideal match for probe rise times
• Outputs a trigger signal via a connected oscilloscope's EXT input to signal fall time at the center of the display for convenient time alignment and deskew operations
• May be used with all Teledyne LeCroy oscilloscopes with a ProBus interface; requires firmware version 8.4.1.4 or greater to access automatic triggering setup
