Megger WM6 Insulation/Continuity Tester is available at EquipTestPro.com with fast shipping and great prices.
Megger WM6 Offers
Features
- Pocket-sized, self-powered instrument - no battery maintenance problems
- Tests at 500 VDC
- Stabilized electronic inverter
- Resistance readings given directly on a moving-coil analogue meter
- Simple, two-position function selector switch
- Robust ABS plastic case
Terminal Voltage on Open Circuit (DC)
- Insulation Range: <600V
- Continuity Range: 800mV approx
Terminal Voltage at 1MΩ Load (DC)
- Insulation Range: 500V +10%, -5%
Terminal Current on Short Circuit
- Insulation Range: 1.3mA approx
- Continuity Range: 55mA approx
- Voltage Stability, 160 to 240 RPM
- Insulation Range:
- Ripple Content at 160 RPM on Open Circuit
Measurement Specifications
- Insulation Range: 0 to 200MΩ and ∞
- Continuity Range: 0 to 100Ω
- Accuracy: 1.5mm (0.060") from any marked position on the scale when measured against standard resistors
General Specifications
- Dimensions: 61 x 131 x 98mm (2.4 x 5.1 x 3.9")
- Weight: 650g (1.5 lb)
