Mitutoyo 209-352 Dial Caliper Gauge Internal Type, .40-1.2"
SKU: 209-352
Availability: Regular Price Mitutoyo 209-352 Offers Features These Dial Caliper Gauges are used only as comparison gauges, and should be used along with a Setting Ring or micrometer.The caliper is spring loaded and makes point contact measuring pressure. Range:.40-1.2 inch Graduation: .0005 inch Accuracy: .0015 inch Max Meas Depth L: 3.3 inch Max Groove Depth A: .19 inch Min. Groove Width B: .06 inch Measuring Contacts: B Weight: 200g Mitutoyo
Availability: Regular Price
Mitutoyo 209-352 Offers
Features
These Dial Caliper Gauges are used only as comparison gauges, and should be used along with a Setting Ring or micrometer.The caliper is spring loaded and makes point contact measuring pressure.
- Range:.40-1.2 inch
- Graduation: .0005 inch
- Accuracy: .0015 inch
- Max Meas Depth L: 3.3 inch
- Max Groove Depth A: .19 inch
- Min. Groove Width B: .06 inch
- Measuring Contacts: B
- Weight: 200g
Mitutoyo 209-352 Specifications
Specifications
| Range | 0.4 - 1.2 inch |
| Graduation | 0.0005" |
| Accuracy | ±0.0015" |
| Inch-Metric | Inch |
| Functions | Measuring contacts : Carbide ball ø0.0394" |
What's included with the Mitutoyo 209-352
- Mitutoyo 209-352 Dial Caliper Gauge Internal Type, .40-1.2"
Mitutoyo 209-352 Dial Caliper Gauge Internal Type, .40-1.2". Great savings PLUS Free Shipping when you order today on EquipTestPro.com.
