Mitutoyo 526-124-20 Mechanical Dial Bore Gauge for extra-small holes, 7 to 10 mm, 2-point
SKU: 526-124-20
Availability: Regular Price Mitutoyo 526-124-20 Offers Use the Mitutoyo 526-124 Mechanical Dial Bore Gauge for extra-small holes to accurately measure miniscule targets. With 6 anvils, 1 needle and a 2-point design, it allows you to achieve fast, precise results. Features Accurately measures extra-small hole diameters in millimeters With 6 anvils and 1 needle for precise readings Mechanical with a clear, easy-to-read dial (2019SB-10 ) Compatibl
Availability: Regular Price
Mitutoyo 526-124-20 Offers
Use the Mitutoyo 526-124 Mechanical Dial Bore Gauge for extra-small holes to accurately measure miniscule targets. With 6 anvils, 1 needle and a 2-point design, it allows you to achieve fast, precise results.
Features
- Accurately measures extra-small hole diameters in millimeters
- With 6 anvils and 1 needle for precise readings
- Mechanical with a clear, easy-to-read dial (2019SB-10 )
- Compatible with 215-120-10 bore gauge stand (not included) for measurement of multiple small holes
- Radial displacement of split-ball contact is converted to axial displacement of measuring rod
- 2-point design
Mitutoyo 526-124-20 Specifications
Specifications
| Minimum Metric Measurement | 7 mm |
| Accuracy | 4 μm |
| Maximum Metric Measurement | 10 mm |
| Graduation | 0.001 mm |
| Supported Measurement Unit(s) | Metric |
| Indication Stability | 2 μm |
| Graduation Measurements | Millimeters |
| Maximum Probe Depth | 56 mm |
What's included with the Mitutoyo 526-124-20
- Mitutoyo 526-124-20 Mechanical Dial Bore Gauge for extra-small holes, 7 to 10 mm, 2-point
Mitutoyo 526-124-20 Mechanical Dial Bore Gauge for extra-small holes, 7 to 10 mm, 2-point. Great savings PLUS Free Shipping when you order today on EquipTestPro.com.
