Triplett MG600 OffersWork with this insulation tester that features a backlit 6000 count display, a bar graph, and a timed test function (1 to 15 minutes in 1-minute increments). In addition, it has a CAT IV 600 V safety category, a locking power function for hands-free operation, data Hold to "freeze" the reading on display, plus a built-in battery check and live circuit voltage indicator.
Features
Applications
| Insulation Range | 6 MΩ, 60 MΩ, 600 MΩ, 6 GΩ, 60 GΩ |
| Accuracy | ±2.5% |
| Resolution | 0.005 MΩ |
| Test Voltages | 500, 1000, 2500, 5000 V |
| AC/DC Voltage | 600 V |
| Resistance | 600 Ω, 6 kΩ |
| Display | 6000 count LCD display with bargraph |
| Sampling Rate | 2.5 times per second |
| Over Range Indication | OL appears on the LCD |
| Short Circuit Current | Approximately 1 mA |
| Open Circuit Test Voltage | ≥4.5 V |
| Low Battery Indication | Battery symbol appears on the LCD |
| Fuse | 500 mA/600 V (0.24 x 1.26"/6 x 32 mm) ceramic 3AG fast blow |
| Temperature | Operating: 32 to 104°F (0 to 40°C)Storage: 14 to 140°F (-10 to 60°C) |
| Humidity | <80% RH (operating and storage) |
| Altitude | Up to 6561.68' (2000 m) |
| Safety | Pollution °2, Meets IEC 61010-1 and IECCategory: CAT IV 600 V |
| Standards/Ratings | 61010-031 |
| Continuity | <50 Ω |
| Power | (8) C batteries or AC Adapter |
| Dimensions | 7.8 x 5.8 x 3.4" (198 x 148 x 86 mm) |
| Weight | 3.2 lbs (1.4 kg) |
